Specifications:
Top Speed 96 km/h
Range 84 km
Battery 72V 40AH Lithium LG Cells
Suspension Front Inverted Forks
Suspension Rear Single Shock Absorber
Disply TFT
Max Power 13000 W
Braking Type Standard
Brakes F: Hydraulic Disc, R: Hydralic Disc
Prime Drive Chain
Tyres F: 70/100-19, R: 80/100-19
Vechicle:
Chassis Material 6061 T4 & T6 aluminium alloy
Process Method Forged under 6,000 tonnes of pressure
Surface Method Anodizing
Head Lights LED
Front Fork Adjustable air + spring (220mm travel)
Rear Fork Adjustable 85mm travel with linkage
Wheel Size 1.4 x 19 in. front / 1.6 x 19 in. rear
Tires FR 70/100-19 / RR 80/100-19 Off – Road tires
Max Range 120 km at 25 km/h
Net Weight 74kg with battery
Vehcle Dimensions 1,880 x 770 x 1,088 mm
Seat Height 840 mm
Handlebar Length 760 mm
Ground Clearance 300 mm
Max Climbing Angle 45˚
Max Recommanded Load 100 kg
Brakes Hydraulic FR / RR improved 4 – piston calipers
Brake Disc 220 mm x 3 mm (front/rear)
Power:
Nominal Voltage 72 (DC)
Max Speed Factory limited to 32 km/h
Torque 500 Nm
Rated Power 5.5 kw (unrestricted)
Peak Power 13.4 kw (unrestricted)
Power Mode Eco / Sport / Hyper
Motor:
Motor Type DC IPM
Mounting Position Mid-mounting
Motor Cooling Air-cooled
Transmission:
Primary Transmission Gearbox
Drive Transmission 428 – 108 T chain
Rear Sprocket 48 T
Key Features:
Motor: 13.4kW (peak) interior Permanent Magnet (IPM) Motor.
Battery: 72V 40AH with Samsung 50S Cell.
Top Speed: Over 95 km/h.
Torque: 5OO Nm ( at wheel ).
Transmission: Direct Gear Drive ( no belt!!!).
Riding Modes: Eco / Sport / Hyper.
Chassis & Suspenstion:
Weight: 74 – 76 kg.
Front Fork: Adjustable 220mm travel.
Rear Shock: Adjustable 85mm travel with linkage.
Frame Material: 6061 T4 & T6 Aluminum Alloy.
Ground Clearance: 300mm
Brakes & Wheels:
Brakes: 4 – Pistion Hydraulic (220mm x 3mm thick rotors).
Regenerative Braking: Yes ( adjustable ).
Wheels: 19-inch front / 19-inch rear.
Dimensions & Range:
Range: Approx. 100km at 25km/h ( up to 120km depending on conditions).
Dimensions: 1,880 mm x 770 mm x 1,088 mm
Seat Height: 850mm
Key Upgrades:
TFT Display: colour display with speed, battery level & voltage.
Gearbox: Internal reinforced gearbox for improved reliability.
Upgraded Brakes: Thicker rotors (3mm vs 2.3mm on MX4) & larger, redesigned
master cylinders.
